Yamaha Snowmobile (84-89) - Shop Manual

Yamaha Snowmobile (84-89) - Shop Manual
39,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 1.56 kg

Verfügbarkeit: Auf Lager

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle:

PZ480 Phazer (1984-1989)
EX570 Exciter (1987-1989)

Seitenzahl: 472

Baujahre: 1984-1989

ODER
Beschreibung

Details

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Ignition system (1984 PZ480H) / Ignition system (1984 PZ480SEH) / Ignition system (1985-on PZ480 and EX570) / Battery charging system (PZ480 and EX570 models with electric start) / Lighting system / Electric starting system / Fuel system / Engine / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Two-stroke fuel mix mixture / Oil tank / Chain housing / Oil level check and change / Maintenance / Engine mounts and fasteners / Fan belt tension check adjustment / Coolant check draining change / Recoil starter / Ski runners / Starter cable adjustment / Decompression cable adjustment / Throttle cable / Oil pump cable / Guide wheel / Track adjustment alignment / Oil filter inspection replacement / Fuel filter / Tune-up / Torque cylinder head nuts / Cylinder compression check test / Spark plug / Ignition timing / Carburetor synchronization / Idle speed / Idle mixture / Specifications

CHAPTER FOUR / HIGH ALTITUDE AND REAR SUSPENSION ADJUSTMENT
Carb tuning / Clutch tuning / Gearing / Suspension adjustment / Specifications

CHAPTER FIVE / ENGINE (PZ480)
Engine lubrication / Service precautions / Serial numbers / Servicing the engine in the frame / Engine removal and installation / Engine top end / Cylinder / Piston, wrist pin and rings / Reed valve assembly / Cooling fan / Drive gear unit / Crankcase and crankshaft /Specifications

CHAPTER SIX / ENGINE (EX750)
Engine lubrication / Service precautions / Serial numbers / Servicing the engine in the frame / Engine removal and installation / Engine top end / Cylinder / Piston, wrist pin and rings / Crankcase and crankshaft /Specifications

CHAPTER SEVEN / FUEL AND EXHAUST SYSTEMS
Air box filter / Carburetor / Fuel pump / Fuel tanks / Exhaust stem muffler / Specifications

CHAPTER EIGHT / ELECTRICAL
Battery / Electric starting system / Capacitor discharge system CDI / Ignition coil / Ignition unit / Rectifier / Voltage regulator / Switches / Instrument panel warning light / Oil level gauge testing / Thermoswitch testing / Throttle override system / Hand warmer assembly / Lighting headlight taillight head tail / Meter assembly instrument cluster / Fuses / Wiring diagrams schematics/ Specifications

CHAPTER NINE / OIL INJECTION SYSTEM
Oil pump service removal installation / Specifications

CHAPTER TEN / LIQUID COOLING SYSTEM
Thermostat / Water pump / Heat exchanger / Hoses / Specifications

CHAPTER ELEVEN / RECOIL STARTER
Specifications

CHAPTER TWELVE / DRIVE SYSTEM
Drive unit / Primary sheave assembly / Secondary sheave assembly / Drive belt / Specifications

CHAPTER THIRTEEN / BRAKE, CHAINCASE , JACKSHAFT AND DRIVESHAFT
Drive chain and sprockets / Chain case, brake caliper and jack shaft / Drive shaft / Specifications

CHAPTER FOURTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Steering assembly / Specifications

CHAPTER FIFTEEN / TRACK AND REAR SUSPENSION
Rear suspension / Slide runner / Shock absorber / Front pivot arm / Rear pivot arm / Suspension and guide wheels / Track / Specifications

CHAPTER SIXTEEN / OFF-SEASON STORAGE
