Ski-Doo Snowmobile (85-89) - Shop Manual

Ski-Doo Snowmobile (85-89) - Shop Manual
39,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 1.56 kg

Verfügbarkeit: Auf Lager

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle:

Ski-Doo Formula MX (1985-1989)
Ski-Doo Formula MX High Altitude H/A (1986)
Ski-Doo Formula Plus (1985-1989)
Ski-Doo Formula MX LT (1987-1989)
Ski-Doo Formula Plus LT (1989)
Ski-Doo Formula Mach I (1989)

Seitenzahl: 400

Baujahre: 1985-1989

ODER
Beschreibung

Details

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Gasket remover / Expendable supplies / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Testing electrical components / Engine electrical system troubleshooting / Voltage regulator / Fuel system / Engine / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE-LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Break-in / Correct fuel mixing / Maintenance schedule intervals / Engine oil tank change / Chaincase oil change / Spindle lubrication / Slide suspension lubrication / Speedometer drive adapter / Cooling system / Coolant level check change inspection / Daily maintenance / Drive belt check / Headlight taillight check / Steering bolt / Carburetor jetting / Weekly maintenance / Recoil starter / Ski and runner alignment / Track adjustment / Fuel filter / Water pump belt / Drive chain reverse gear / Cylinder head torque / Tune-up / Compression check / Two-stroke pressure test / Cylinder head torque / Spark plug plugs / Ignition timing / Dynamic timing / Static timing / Carburetor synchronization / Idle speed / Specifications

CHAPTER FOUR / HIGH ALTITUDE AND REAR SUSPENSION ADJUSTMENT
Clutch tuning / Carburetor tuning / Gearing / Suspension adjustment /Specifications

CHAPTER FIVE / ENGINE
Engine and chassis serial numbers / Engine removal installation / Engine plate and mounts / Engine top end / Cylinder head / Cylinder housing / Pistons / Piston rings / Wrist pins / Connecting rods / Small end bearings / Reed valve / Crankcase / Crankshaft / Pinion gear / Rotax automatic variable exhaust RAVE /Rotary valve and shaft / Specifications

CHAPTER SIX / FUEL AND EXHAUSTS
Air silencer / Carburetor / Fuel Pump / Fuel tank / Fuel valve / Throttle cable / Exhaust / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Flywheel and stator / Battery / Ignition coil coils / Capacitor discharge ignition CDI / CDI control unit / CDI Box / Voltage regulator / Lighting system / Instrument cluster gauges / Switches / Fuel level sensor / Oil level indicator / Electric starter system / Circuit breaker / Hand warmers / Wiring diagrams / Specification

CHAPTER EIGHT / OIL INJECTION SYSTEM
Oil pump / Specification

CHAPTER NINE / LIQUID COOLING SYSTEM
Thermostat / Water pump / Heat exchanger / Check valve / Hoses / Specifications

CHAPTER TEN / RECOIL STARTER

CHAPTER ELEVEN / DRIVE SYSTEM

Drive unit / Drive pulley / Drive belt / Specifications

CHAPTER TWELVE / BRAKE, CHAINCASE, JACKSHAFT AND DRIVE AXLE
Drive chain and sprockets / Chaincase / Jackshaft / Drive axle / Brake pad and caliper / Hydraulic brake system / Specifications

CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Shock absorbers / Steering assembly / Specifications

CHAPTER FOURTEEN / TRACK AND REAR SUSPENSION
Rear suspension / Slide shoes / Runner protector / Shock absorbers / Front shackle / Front swing arm / Front arm / Rear shackle / Rear arm / Rear axle / Suspension and guide wheels / Track / Specifications

CHAPTER SEVENTEEN / OFF SEASON STORAGE

Zusatzinformation
Artikelnummer CLY-S829
Verlag Clymer Service Manuals
Format DIN A4
Versandfertig in: 24 Stunden
