Suzuki LT-Z400 (03-08) - Reparaturanleitung

Tec-Verlag GmbH
Artikel Nr: CLY-M2702
In stock
34,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 0.91 kg

Verfügbarkeit: Sofort versandfertig, Lieferfrist 1-3 Tage

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle: Suzuki LT-Z400 Quadsport

Seitenzahl: 336

Baujahre: 2003-2008

Beschreibung

Produktdetails zu Suzuki LT/Z400 (03/08) / Reparaturanleitung mit 336 Seiten

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch.  Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

 QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION

Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Water damage / Starting the engine / Engine does not start / Poor idle speed performance / Poor, medium and high speed performance / Electrical testing / Starting system / Charging system / Ignition system / Lighting system / Fuel system / Engine overheating / Engine noises / Cylinder leakdown test / Clutch / Transmission / Suspension / Frame / Brakes

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Maintenance schedule / Pre-Ride inspection / Air box drain plug / Air filter / Engine oil / Oil pressure check / Spark plug / Spark arrestor cleaning / Fuel line inspection / Fuel tank vent hose / Carburetor / Ignition timing / Valve clearance inspection / Compression check / Control cables / Cooling system / Tires and wheels / Battery / Drive chain and sprockets / Brake system / Shock absorbers / Front suspension / Swing arm bearing inspection / Rear suspension inspection / Skid plate inspection / Specifications

CHAPTER FOUR / ENGINE TOP END
Break-In period / Exhaust system / Cylinder head cover / Camshafts and cam chain tensioner / Cylinder head / Valves / Cylinder / Piston and piston rings / Specifications

CHAPTER FIVE / ENGINE LOWER END
Engine / Crankcase / Crankcase seals / Crankcase bearings / Engine balancer / Oil pump / Oil strainer / Oil pressure check valve / Oil tank / Crankshaft / Cam chain and rear guide / Balancer driven gear / Primary and balancer drive gears / Specifications

CHAPTER SIX / CLUTCH AND EXTERNAL SHIFT MECHANISM
Right crankcase cover / Clutch / Clutch release camshaft / Shift lever / Shift mechanism / Clutch cable replacement / Clutch lever replacement / Reverse shift cable replacement / Specifications

CHAPTER SEVEN / TRANSMISSION AND INTERNAL SHIFT MECHANISM
Transmission operation / Transmission service / Input shaft / Output shaft / Reverse gear and axle / Transmission inspection / Shift drum and forks / Specifications

CHAPTER EIGHT / FUEL SYSTEM
Carburetor / Throttle position sensor / Carburetor operation / Fuel valve / Throttle cable replacement / Choke cable replacement / Fuel tank / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Electrical component replacement / Alternator cover / Lower idle gear / Stator assembly / Rotor and starter clutch / Starter / Starting system switches / Ignition system / Charging system / Radiator fan system / Coolant temperature warning circuit / Headlight / Taillight / Meter lights / Switches / Specifications

CHAPTER TEN / COOLING SYSTEM
Safety precautions / Fan and fan switch / Radiator / Thermostat / Water pump / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Tie rods / Steering knuckle / Control arms / Ball joint replacement / Shock absorbers / Handlebar / Steering shaft / Tires and wheels / Specifications

CHAPTER TWELVE / REAR SUSPENSION
Rear wheel / Rear wheel hubs / Rear axle / Rear axle housing / Sprockets / Drive chain / Shock absorber / Shock linkage / Swing arm / Specifications

CHAPTER THIRTEEN / BRAKE SYSTEM
Brake service / Front brake pads / Front brake caliper / Front master cylinder / Rear brake pads / Rear brake caliper / Rear master cylinder / Rear brake pedal / Brake system draining / Brake system bleeding / Brake disc / Parking brake / clutch lever / Specifications

CHAPTER FOURTEEN / BODY
Retaining clips / Seat / Upper fuel tank cover / Side covers / Headlight cover / Front fender / Rear fender / Footpegs and footguard

INDEX

COLOR WIRING DIAGRAMS


Zusatzinformation
Artikelnummer CLY-M2702
Versandfertig in: 24 Stunden
