Suzuki DR 650 SE (96-13) - Reparaturanleitung

Tec-Verlag GmbH
Artikel Nr: CLY-M272
In stock
36,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 0.82 kg

Verfügbarkeit: Sofort versandfertig, Lieferfrist 1-3 Tage

Artikelart: Werkstatthandbuch

Sprache: Englisch

Artikelzustand: Neu

Seitenzahl: 304

Baujahre: 1996 - 2013

Modelle: Suzuki DR650SE

Nur noch 1 auf Lager

Beschreibung

Produktdetails zu Suzuki DR 650 SE (96/13) / Reparaturanleitung mit 304 Seiten

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

Chapter One / General Information
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Tools / Measuring tools / Electrical system fundamentals / Service methods / Storage / Specifications Specs

Chapter Two / Troubleshooting
Starting the engine / Engine spark test / Engine performance / Electrical testing / Starting system / Engine noise / Motorcycle noise / Engine lubrication / Engine leakdown test / Clutch / Gearshift linkage and transmission / Brakes / Disc brake troubleshooting / Specifications Specs

Chapter Three / Lubrication, Maintenance and Tune-up
Periodic inspection / Tune-up / Air filter / Engine oil and filter / Idle speed adjustment / Spark plugs / Compression test / Ignition timing inspection / Brake system / Clutch / Fuel hose inspection / Emission control system / Throttle cables / Choke cable / Tires and wheels / Valve clearance / Lights and horn inspection / Sidestand switch and ignition cut-off system / Steering head bearing inspection / Front suspension inspection / Front fork oil change / Rear suspension inspection / Drive chain / Speedometer cable / Muffler / Fasteners / Specifications Specs

Chapter Four / Engine Top End
Exhaust system / Cylinder head cover / Rocker arm assemblies / Camshaft / Cylinder head / Valves / Cam chain tensioner / Cylinder / Piston, piston pin and piston rings / Specifications Specs

Chapter Five / Engine Lower End
Left crankcase cover / Starter idler gear and torque limiter / Flywheel alternator rotor and starter clutch / Right crankcase cover / Camshaft chain / Oil pump / Primary drive gear / Crankshaft ring nut / Crankcase / Countershaft seal / Crankcase bearings / Balancer assembly / Oil screen / Oil jet / Crankshaft / Break-in / Specifications Specs

Chapter Six / Clutch and External Shift Mechanism
Clutch / Clutch release mechanism / External shift mechanism / Clutch cable replacement / Specifications Specs

Chapter Seven / Transmission and Internal Shift Mechanism
Mainshaft / Countershaft / Transmission inspection / Shift drum and forks / Specifications Specs

Chapter Eight / Fuel and Emission Control System
Carburetor / Pilot screw / Carburetor float height / Throttle cables / Choke cable / Air box / Fuel tank / Fuel valve / Crankcase breather system / Evaporative emissions control system / Specifications Specs

Chapter Nine / Electrical System
Continuity testing guidelines / Electrical connectors / Negative battery terminal / Battery / Charging system / Alternator / Regulator/rectifier / Starting system / Starter / Starter relay / Ignition system / Ignition interlock system / Lighting system / Switches / Fuses / Specifications Specs

Chapter Ten / Oil Cooler and Hoses
Oil cooler guard / Rear oil hose / Specifications Specs

Chapter Eleven / Wheels, Tires and Drive Chain
Front wheel / Rear wheel / Front and rear hubs / Rim and spoke service / Drive chain / Drive sprocket cover / Sprockets / Tire changing / Specifications Specs

Chapter Twelve / Front Suspension and Steering
Handlebar / Lower handlebar holders / Right handlebar grip replacement / Left handlebar grip replacement / Throttle grip replacement / Balancer weights / Front fork / Steering stem and head / Specification Specs

Chapter Thirteen / Rear Suspension
Shock absorber / Shock absorber linkage / Swing arm / Shock absorber adjustment / Specifications Specs

Chapter Fourteen / Brakes
Brake service / Front brake pads / Front brake caliper / Front master cylinder / Rear brake pads / Rear brake caliper / Rear master cylinder / Rear brake pedal / Brake system draining / Brake system bleeding / Brake disc / Specifications Specs

Chapter Fifteen / Body
Side covers / Seat / Headlight cowl / Footpegs / Front fender / Rear fender extension / Rear rack / Passenger grip / Rear fender / Inner Rear fender / Specifications Specs

Index

Color Wiring Diagrams
