Honda XR50R, CRF50F, XR70R, CRF70F (97-09) - Reparaturanleitung

Tec-Verlag GmbH
Artikel Nr: CLY-M3193
In stock
32,95 €
Inkl. 5% MwSt., zzgl. Versandkosten
Versandgewicht: 0.62 kg

Verfügbarkeit: Sofort versandfertig, Lieferfrist 1-3 Tage

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Seitenzahl: 230

Baujahre: 1997 - 2009

Modelle: 2004-2009 HONDA CRF50F
2004-2009 HONDA CRF70F
2000-2003 HONDA XR50R
1997-2003 HONDA XR70R

Nur noch 1 auf Lager

Beschreibung

Produktdetails zu Honda XR50R, CRF50F, XR70R, CRF70F (97/09) / Reparaturanleitung mit 230 Seiten

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING

Operating requirements / Starting the engine / Starting difficulties / Engine is difficult to start / Poor idle speed performance / Poor medium and high speed performance / Ignition system / Fuel system / Engine overheating / Engine / Engine noises / Cylinder leakage test / Clutch / Transmission / Front suspension and steering / Brakes

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride inspection / Maintenance schedule / Tires and wheels / Lubrication / Periodic maintenance / Engine tune-up / Specifications

CHAPTER FOUR / ENGINE TOP END
Exhaust system / Camshaft / Cylinder head / Valves and valve components / Cylinder / Piston and piston rings / Specifications

CHAPTER FIVE / ENGINE LOWER END
Servicing engine in frame / Engine removal installation / Left crankcase cover / Camshaft chain and tensioner / Oil pump / Crankcase and crankshaft / Kickstarter / Specifications

CHAPTER SIX / CLUTCH AND PRIMARY DRIVE GEAR
Right crankcase cover / Clutch / Clutch release mechanism / Primary drive gear / Specifications

CHAPTER SEVEN / TRANSMISSION AND SHIFT MECHANISM
External shift mechanism / Transmission overhaul / Transmission inspection / Internal shift mechanism

CHAPTER EIGHT / FUEL SYSTEM
Carburetor / Float level / Carburetor adjustments / Fuel tank / Fuel valve / Crankcase breather system / Specifications

CHAPTER NINE / IGNITION SYSTEM
Capacitor discharge ignition / Flywheel / Stator plate assembly / Switches / Specifications

CHAPTER TEN / WHEELS, TIRES AND DRIVE CHAIN
Bike stand / Front wheel / Rear wheel / Wheel inspection / Front hub / Rear hub / Tire changing / Tire repairs / Sprocket replacement / Drive chain / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING (XR50R AND CRF50F)
Handlebar / Steering head / Front fork / Specifications

CHAPTER TWELVE / FRONT SUSPENSION AND STEERING (XR70R AND CRF70F)
Handlebar / Steering head / Front fork / Specifications

CHAPTER THIRTEEN / REAR SUSPENSION
Shock absorber / Swing arm / Specifications

CHAPTER FOURTEEN / BRAKES
Front and rear brake / Front brake cable / Specifications

CHAPTER FIFTEEN / BODY
Retaining clips / Seat / Rear side cover / Specifications

INDEX

WIRING DIAGRAMS
