Polaris Snowmobil (84-89) - Shop Manual

Polaris Snowmobil (84-89) - Shop Manual
39,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 1.56 kg

Verfügbarkeit: Auf Lager

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle:

Indy Trail (1984-1989)
Indy 400 (1984-1989)
Indy 600 (1984-1987)
Indy Sport (1987-1989)
Indy 650 (1988-1989)
Indy 500 (1989)

Seitenzahl: 488

Baujahre: 1984-1989

ODER
Beschreibung

Details

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.



QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Gasket remover / Expendable supplies / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Testing electrical components / Engine electrical system troubleshooting / Alternator output test / Voltage regulator / Charging system (models with electric starting) / Electric starting system / Fuel system / Engine / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Break-in / Correct fuel mixing / Maintenance schedule intervals / Engine oil tank change / Chaincase oil change / Spindle lubrication / Slide suspension lubrication / Speedometer drive adapter / Cooling system / Coolant level check change inspection / Daily maintenance / Drive belt check / Headlight taillight check / Steering bolt / Carburetor jetting / Weekly maintenance / Recoil starter / Ski and runner alignment / Track adjustment / Fuel filter / Water pump belt / Drive chain reverse gear / Cylinder head torque / Tune-up / Compression check / Two-stroke pressure test / Cylinder head torque / Spark plug plugs / Ignition timing / Dynamic timing / Static timing / Carburetor synchronization / Idle speed / Specifications

CHAPTER FOUR / ADJUSTMENTS FOR SPECIAL USE
High altitude / Carburetor tuning / Clutch tuning / Gearing / Suspension / Specifications

CHAPTER FIVE / TWO-CYLINDER ENGINES
Engine lubrication / Service precautions / Serial numbers / Servicing the engine in the frame / Engine removal / Engine plate / Engine installation / Engine top end / Cylinder / Piston, wrist pin and piston rings / Crankcase and crankshaft / Specifications

CHAPTER SIX / THREE-CYLINDER ENGINES
Engine lubrication / Service precautions / Serial numbers / Servicing the engine in the frame / Engine removal / Engine plate / Engine installation / Engine top end / Cylinder / Piston, wrist pin and piston rings / Crankcase and crankshaft / Specifications

CHAPTER SEVEN / FUEL AND EXHAUST SYSTEMS
Air box / Carburetor / Fuel Pump / Fuel tank / Throttle cable / Exhaust / Specifications

CHAPTER EIGHT / ELECTRICAL SYSTEM
Battery / Ignition coil coils / Capacitor discharge ignition CDI / CDI control unit / Voltage regulator / Lighting system / Instrument cluster gauges / Switches / Fuel level sensor / Oil level indicator / Electric starter system / Wiring diagrams / Specification

CHAPTER NINE / OIL INJECTION SYSTEM
Oil pump / Specification

CHAPTER TEN / LIQUID COOLING SYSTEM
Water pump / Heat exchanger / Specifications

CHAPTER ELEVEN / RECOIL STARTER

CHAPTER TWELVE-DRIVE SYSTEM
Drive unit / Primary sheave / Secondary sheave / Drive belt / Specifications

CHAPTER THIRTEEN / DISC BRAKE
Brake pad replacement / Brake caliper / Master cylinder / Front brake hose / Brake disc /Specifications

CHAPTER FOURTEEN / CHAINCASE, JACKSHAFT AND DRIVESHAFT
Drive chain and sprockets / Chaincase / Jackshaft / Driveshaft / Specifications

CHAPTER FIFTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Shock absorbers / Steering assembly / Specifications

CHAPTER SIXTEEN / TRACK AND REAR SUSPENSION
Rear suspension / Rail tips / Hi-Fax / Steering assembly / Specifications

CHAPTER FIFTEEN / OFF SEASON STORAGE

Zusatzinformation
Artikelnummer CLY-S832
Format DIN A4
Versandfertig in: 24 Stunden
