Arctic Cat Snowmobile (90-98) - Shop Manual

Arctic Cat Snowmobile (90-98) - Shop Manual
39,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 1.56 kg

Verfügbarkeit: Auf Lager

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle:

Cougar
Cougar 2-Up
Cougar Deluxe
Cougar Mountain Cat
EXT 550
EXT 550 Mountain Cat
EXT 580
EXT 580 DLX
EXT 580 EFI
EXT 580 EFI Deluxe
EXT 580 EFI Mountain Cat
EXT 580 Mountain Cat
EXT 600
EXT 600 Triple
EXT 600 Triple Touring
EXT EFI
EXT EFI Deluxe
EXT Triple Touring
El Tigre EXT
El Tigre EXT Special
El Tigre Mountain Cat
Pantera
Panther
Powder Extreme
Powder Special
Powder Special EFI
Prowler
Prowler Mountain Cat
Panther 440
Panther 550
Prowler 2-Up
Prowler II
Prowler Special
440
Z 440
ZL 440
ZL 500
ZR 440
ZR 580
ZR 600
ZR 600 EFI
ZR580 EFI
ZRT 600

Seitenzahl: 504

Baujahre: 1990-1998

ODER
Beschreibung

Details

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Gasket remover / Expendable supplies / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Testing electrical components / Engine electrical system troubleshooting / Voltage regulator / Fuel system / Electronic Fuel Injection EFI / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Break-in / Correct fuel mixing / Maintenance schedule intervals / Engine oil tank change / Chaincase oil change / Spindle lubrication / Slide suspension lubrication / Speedometer drive adapter / Cooling system / Coolant level check change inspection / Daily maintenance / Drive belt check / Headlight taillight check / Steering bolt / Carburetor jetting / Weekly maintenance / Recoil starter / Ski and runner alignment / Track adjustment / Fuel filter / Water pump belt / Drive chain reverse gear / Cylinder head torque / Tune-up / Compression check / Two-stroke pressure test / Cylinder head torque / Spark plug plugs / Ignition timing / Dynamic timing / Static timing / Carburetor synchronization / Idle speed / Specifications

CHAPTER FOUR / ADJUSTMENTS FOR SPECIAL USE
Carburetor tuning / Clutch tuning / Gearing / Suspension / Specifications

CHAPTER FIVE / ENGINES
Engine and chassis serial numbers / Engine removal installation / Engine plate and mounts / Engine top end / Cylinder head / Cylinder housing / Pistons / Piston rings / Wrist pins / Connecting rods / Small end bearings / Reed valve / Crankcase / Crankshaft / Pinion gear / Water pump / Specifications

CHAPTER SIX / FUEL SYSTEM CARBURETED MODELS
Air silencer / Carburetor /Altitude compensator / Fuel tank / Throttle cable / Specifications

CHAPTER SEVEN / FUEL SYSTEM FUEL INJECTED MODELS
Electronic fuel injection EFI / Troubleshooting / Adjustment / Specifications

CHAPTER EIGHT / EXHAUST SYSTEM

CHAPTER NINE / ELECTRICAL SYSTEM

Flywheel and stator assembly / Ignition coil / Capacitor discharge ignition CDI / Voltage regulator / Lighting system / Instrument cluster gauges / Switches / Fuel level sensor / Oil level indicator / Electric starter / Wiring diagrams / Specification

CHAPTER TEN / OIL INJECTION SYSTEM
Oil pump / Specification

CHAPTER ELEVEN / COOLING SYSTEM
Fan cooled / Liquid cooled / Thermostat / Water pump / Heat exchanger / Specifications

CHAPTER TWELVE / RECOIL STARTER

CHAPTER THIRTEEN / DRIVE SYSTEM

Drive unit / Primary sheave / Secondary sheave / Drive belt / Specifications

CHAPER FOURTEEN / BRAKE, CHAINCASE, DROPCASE AND DRIVESHAFT
Drive chain and sprockets / External chain tensioner / Drive shaft / Driven shaft / Mechanical brake system / Hydraulic brake system / Specifications

CHAPTER FIFTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Shock absorbers / Steering assembly / Specifications

CHAPTER SIXTEEN / TRACK AND REAR SUSPENSION
Rear suspension / End caps / Wear strips / Rear suspension assembly / Rear springs / Suspension and guide wheels / Idler wheels / Rear axle / Track / Specifications

CHAPTER FIFTEEN / OFF SEASON STORAGE
