Arctic Cat Snowmobile (88-89) - Shop Manual

Arctic Cat Snowmobile (88-89) - Shop Manual
39,95 €
Inkl. 7% MwSt., zzgl. Versandkosten
Versandgewicht: 1.56 kg

Verfügbarkeit: Auf Lager

Artikelart: Reparaturanleitung

Sprache: Englisch

Artikelzustand: Neu

Modelle:

Wildcat 650 (1988-1989)
El Tigre EXT (1989)

Seitenzahl: 400

Baujahre: 1988-1989

ODER
Beschreibung

Details

Clymer Reparaturanleitungen zählen zu den besten und umfangreichsten Reparaturanleitungen auf dem Markt und sind qualitativ und quantitativ auf dem Niveau des original Händler Werkstatthandbuch. Pflegen, warten, reparieren - alle Arbeiten sind detailliert beschrieben und durch viele Abbildungen erläutert.

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Safety first / Service hints / Engine and chassis serial numbers / Engine operation / Torque specifications / Fasteners / Lubricants / RTV gasket sealant / Threadlock / Gasket remover / Basic hand tools / Precision measuring tools / Special tools / Mechanic¿s tips / Ball bearing replacement / Oil Seals / Snowmobile operation / Snowmobile safety / Snowmobile code of ethics / Specifications

CHAPTER TWO / TROUBLESHOOTING
Operating requirements / Troubleshooting instruments / Testing electrical components / Engine electrical system troubleshooting / Voltage regulator / Electric starting system (optional on El Tigre EXT) / Fuel system / Engine / Two-stroke pressure testing / Power train / Skis and steering / Track assembly

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Pre-ride checks inspection / Break-in / Correct fuel mixing / Maintenance schedule intervals / Engine oil tank change / Chaincase oil change / Spindle lubrication / Slide suspension lubrication / Speedometer drive adapter / Cooling system / Coolant level check change inspection / Daily maintenance / Drive belt check / Headlight taillight check / Steering bolt / Carburetor jetting / Weekly maintenance / Recoil starter / Ski and runner alignment / Track adjustment / Fuel filter / Water pump belt / Drive chain reverse gear / Cylinder head torque / Tune-up / Compression check / Cylinder head torque / Spark plug plugs / Ignition timing / Dynamic timing / Static timing / Carburetor synchronization / Idle speed / Specifications

CHAPTER FOUR / HIGH ALTITUDE ADJUSTMENTS
Carburetor tuning / Clutch tuning / Gearing / Suspension / Specifications

CHAPTER FIVE / ENGINES
Engine and chassis serial numbers / Engine removal installation / Engine plate and mounts / Engine top end / Cylinder head / Cylinder housing / Pistons / Piston rings / Wrist pins / Connecting rods / Small end bearings / Reed valve / Crankcase / Crankshaft / Pinion gear / Water pump / Specifications

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air silencer / Carburetor / Fuel pump / Fuel tank / Throttle cable / Exhaust system / Muffler / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Battery / Capacitor discharge ignition CDI / CDI box / Ignition coil / Voltage regulator / Electric starting system / Lighting / Meter assembly / Gauges / Switches / Oil level gauge / Fuses / Wiring diagrams / Specification

CHAPTER EIGHT / OIL INJECTION SYSTEM
Oil pump / Specification

CHAPTER NINE / LIQUID COOLING SYSTEM
Thermostat / Water pump / Heat exchanger / Specifications

CHAPTER TEN / RECOIL STARTER

CHAPTER ELEVEN / DRIVE SYSTEM
Drive unit / Primary sheave / Secondary sheave / Drive belt / Specifications

CHAPER TWELVE / BRAKE, CHAINCASE, JACKSHAFT AND DRIVE AXLE
Drive chain and sprockets / Jackshaft / Drive axle / Front brake / Reverse / Specifications

CHAPTER THIRTEEN / FRONT SUSPENSION AND STEERING
Skis / Front suspension / Shock absorbers / Steering assembly / Specifications

CHAPTER FOURTEEN / TRACK AND REAR SUSPENSION
Rear suspension / End caps / Wear strips / Rear suspension assembly / Suspension and guide wheels / Track / Specifications

CHAPTER FIFTEEN / OFF SEASON STORAGE

INDEX

WIRING DIAGRAMS

Models covered:
1989 Arctic Cat El Tigre EXT
1988 1989 Arctic Cat Wildcat 650


Clymer Manuals Arctic Cat El Tigre Manual
Clymer Manuals Arctic Cat Wildcat 650 Manual


Wildcat 650 (1988-1989)
El Tigre EXT (1989)

Zusatzinformation
Artikelnummer CLY-S835
Verlag Clymer Service Manuals
